TILTING DISC CHECK VALVE

DESIGN FEATURE

  • Design and manufacture to EN12334
  • Epoxy coated body to prevent corrosion
  • Flanges acc. To BS EN1092-2
  • Face-to-face acc. To EN558-1 Series14
  • Inspection& test to EN12266
  • Check valve with lever and counter weight
  • Resilient seated Tilting Check valve
  • Short face-to-face dimension, small volume, and low weight
  • Check valves with lever and counter weight can be installed in vertical or horizontal pipelines (please specify before ordering)
  • The double eccentric disc is kept in the open position; the opening angle of the disc depends on the flow velocity
  • Due to the variable weight, it can be adjusted to individual operating conditions
  • Variants: Weight can be installed on the left or right
  • Flange connection dimension according to EN 1092-2
